Phone: +30 210 412 9441| Weight |
3 , 778 kg |
|---|---|
| Castor type |
Fixed |
| Fitting Type |
Plate Fitting |
| Wheel Material |
Nylon 6 |
| Wheel centre / Rim |
Nylon 6 |
| Wheel Diameter |
85mm |
| Thread Width |
70mm |
| Bearing Type |
Two Ball Bearings |
| Wheel Hole |
20mm |
| Hub Width |
70mm |
| Plate Size |
135mm x 110mm |
| Bolt Hole Spacing |
105mm x 80mm |
| Bolt Hole |
13mm |
| Overall Height |
135mm |
| Load Capacity |
700kg |
| Hardness |
Sh D 70° |
| Floor condition |
Carper , Stoneware , Grid , Concrete |
| Temperature Resistance |
-25°C/+85°C |
| Ball Bearing Seat |
47mm x 14mm |
| Serie |
LGDC/N/NPC |
| Wheel & Castors |
Castor |
| Inox |
No |
| Unit Weight |
3.778Kg |
| Applications |
Storage - Logostic - Transpotation |
ROLLER Ø77Χ70Ø20MM 2R POLYURETHANE 500 KGS
15,60€ ex VAT
ROLLER Ø85Χ75Ø25MM 2R POLYURETHANE 750 KGS
23,40€ ex VAT
CASTOR Ø85X70MM 2R FIXED NYLON (ΕHD)
0,00€ ex VAT
ΕΠΙΚΟΙΝΩΝΗΣΤΕ ΜΑΖΙ ΜΑΣ
Roller made of high-quality, impact-resistant Nylon 6, very low rolling and swivel resistance, smooth running performance on even floor, high abrasion resistance. Hub on shielded ball bearings. Extra heavy duty castor pressed and welded steel, turning on thrust and tapered bearings.
TECHICAL DESCRIPTION
DESCRIPTION
Roller made of high-quality, impact-resistant Nylon 6, very low rolling and swivel resistance, smooth running performance on even floor, high abrasion resistance. Hub on shielded ball bearings. Extra heavy duty castor pressed and welded steel, turning on thrust and tapered bearings.
