Phone: +30 210 412 9441| Weight |
5 , 008 kg |
|---|---|
| Castor type |
Fixed |
| Fitting Type |
Plate Fitting |
| Wheel Material |
Cast Iron |
| Wheel centre / Rim |
Cast Iron |
| Wheel Diameter |
200mm |
| Thread Width |
48mm |
| Bearing Type |
Two Ball Bearings |
| Wheel Hole |
25mm |
| Hub Width |
48mm |
| Plate Size |
135mm x 110mm |
| Bolt Hole Spacing |
105mm x 80mm |
| Bolt Hole |
13mm x 16mm |
| Overall Height |
251mm |
| Load Capacity |
800kg |
| Hardness |
180-220HB |
| Floor condition |
Asphalt , Concrete |
| Temperature Resistance |
-20°C/+120°C |
| Ball Bearing Seat |
52mm x 15mm |
| Serie |
114A |
| Wheel & Castors |
Castor |
| Inox |
No |
| Unit Weight |
5.008Kg |
| Applications |
Industry , Food Industry , Furniture |
CASTOR Ø140MM BOLT HOLE GQ
0,00€ ex VAT
WHEEL Ø180X45X58Ø20MM 2R GREY RUBBER
0,00€ ex VAT
CASTOR Ø200MM FIXED G2R (HD)
51,82€ ex VAT
ΚΑΤΟΠΙΝ ΠΑΡΑΓΓΕΛΙΑΣ
Wheel made of mechanical cast iron, high temperatures resistant with low rolling resistance. Hub on ball bearings with central spacer. Heavy duty castor in zinc-chromium plated pressed steel.
TECHICAL DESCRIPTION
DESCRIPTION
Wheel made of mechanical cast iron, high temperatures resistant with low rolling resistance. Hub on ball bearings with central spacer. Heavy duty castor in zinc-chromium plated pressed steel.
